Fittings / O-SEAL® / 51T-7-6-M

Socketweld Pipe Reducer

Data sheet
American Engineering Trusted Wordwide ®

DATA SHEET

51T-7-6-M
11/07/2025 2:02 AM

Product Category 51T-7-6-M
Part Description Socketweld Pipe Reducer

Dimensions

A 2.000
B-THREAD 3.063" - 12UNS
C 1.19
CRN 0A16860.2
D 1.675
E 0.50
F 1.38

General

Pressure Rating 6000 PSI
Threadpiece Material Monel®, ASTM B164, UNS N04405
CRN 0A16860.2

cpvmfg.com | 484.731.4010

The complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user. Caution: Do not mix or interchange valve components with those of other manufacturers.
